Brand: TP-Link
TP-LINK EAP610 AX1800 DUALBAND WI-FI 6 INDOOR POE ACCESS POINT
TP-LINK EAP610 AX1800 DUALBAND WI-FI 6 INDOOR POE ACCESS POINT
SKU:EAP610
Couldn't load pickup availability
Upgrade to WiFi 6 with speeds up to 1775 Mbps, offering speeds 50% faster than WiFi 5 with the TP-Link EAP610. Omada's Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and routers. It provides 100% centralized cloud management and creates a highly scalable network controlled from a single interface.
Description
Features:
Ultra-Fast WiFi 6 Speeds: 574 Mbps simultaneous on 2.4 GHz and 1201 Mbps on 5 GHz total 1775 Mbps Wi-Fi speeds.
High-Efficiency WiFi 6: More connected devices can enjoy faster speeds.
Centralized Cloud Management: Manage the entire network locally or from the cloud via the web UI or Omada app.
Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.
Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.
PoE+ Powered: Supports DC (adapter included), 802.3at PoE+, and passive PoE for flexible installations.
Ultra-Slim Design: ?160 mm × 33.6 mm The elegant design brings more agility.
Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/Voucher, etc.) and abundant wireless security technologies.
Technical specifications
| TP-Link EAP610: | |
| Features2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer range | 1775 Mbit/s |
| Maximum data transfer speed (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer speed (5 GHz) | 1201 Mbit/s |
| Ethernet LAN, data transfer speed | 1000 Mbit/s |
| Band frequency | 2.4 - 5 GHz |
| Network standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
| Cabling technology | 10/100/1000Base-T(X) |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| VLAN support | Yes |
| Rate limit | Yes |
| Band steering (performance optimization) | Yes |
| Connection fairness (ATF) | Yes |
| Quality of Service (QoS) support | Yes |
| Transmission power (CE) | <20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz, EIRP) |
| Transmission power (FCC) | <25 dBm (2.4 GHz); <25 dBm (5 GHz) |
| SecuritySecurity algorithms supported | WPA,WPA-Enterprise,WPA2,WPA2-Enterprise,WPA3,WPA3-Enterprise |
| MAC, address filter | Yes |
| Access Control List (ACL) | Yes |
| Management featuresWeb-based management | Yes |
| Ports and InterfacesEthernet LAN (RJ-45) quantity of ports | 1 |
| DC input jack | Yes |
| Power controlPower over Ethernet (PoE) | Yes |
| AC input voltage | 12 V |
| Input current | 1 A |
| DesignLocation | Ceiling, Wall |
| Product color | White |
| Reset button | Yes |
| LED indicators | Yes |
| Certification | CE, FCC, RoHS |
| AntennaAntenna type | Internal |
| Environmental conditionsOperating relative humidity range | 10 - 90% |
| Operating temperature range | 0 - 40 °C |
| Storage temperature range | -40 - 70 °C |
| Storage relative humidity range | 5 - 90% |
| Weight and dimensionsWidth | 243 mm |
| Depth | 243 mm |
| Height | 64 mm |
| PackagingNumber of included products | 1 piece(s) |
| AC adapter included | Yes |
| Mounting kit | Yes |
| Packaging type | Box |
Technical data sheet
| Function | Access Point |
