SWITCH TP-LINK TL-SG2008 GIGABIT 8-PORT SMART
SWITCH TP-LINK TL-SG2008 GIGABIT 8-PORT SMART
SKU:SG2008
Couldn't load pickup availability
The TP-LINK TL-SG2008 Smart Gigabit Switch is equipped with 8 Gigabit RJ45 ports. The switch provides high performance, enterprise-level quality of service, essential security strategies, and multiple Layer 2 management features.
Description
Features
Gigabit Ethernet connections on all ports providing maximum data transfer speed
Integrated security strategy including 802.1Q VLAN, ACL, Port Security, and Storm Control that help protect your LAN investment
L2 / L3 / L4 QoS and IGMP snooping that optimize video and voice applications
WEB / CLI, SNMP, RMON management modes that provide numerous administration functions
Innovative energy efficiency technology that saves up to 65% of power consumption
Technical specifications
| Management featuresSwitch type | Managed |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| MIB, support | Y |
| Ports & InterfacesQuantity of basic RJ-45 Ethernet switching ports | 8 |
| Basic RJ-45 Ethernet switching port type | Gigabit Ethernet (10/100/1000) |
| Electrical connector | DC input jack |
| ConnectionNetwork standards | IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
| 10G support | No |
| Copper Ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Supported cable types | Cat3,Cat4,Cat5,Cat5e |
| Port mirroring | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Storm control broadcasting | Yes |
| Rate limiting | Yes |
| Auto MDI / MDI-X | Yes |
| Spanning Tree Protocol | Yes |
| Auto-negotiation | Yes |
| VLAN support | Yes |
| Virtual LAN functions | Voice VLAN |
| Number of VLANs | 512 |
| Data transmissionSwitching capacity | 16 Gbit/s |
| Forwarding rate | 11.9 Mpps |
| MAC address table | 8000 entries |
| Jumbo Frames, support | Yes |
| Jumbo frames | 9216 |
| SecurityAccess Control List (ACL) | Yes |
| IGMP | Yes |
| Supported security algorithms | SSH,SSH-2,SSL/TLS |
| SSH/SSL support | Yes |
| Multicast featuresMulticast, support | Yes |
| DesignProduct color | Black |
| LED indicators | Yes |
| Certification | CE, FCC, RoHS |
| PerformanceFanless | Yes |
| Power controlAC input voltage | 100 - 240 V |
| AC input frequency | 60 Hz |
| DC input voltage | 12 V |
| Input current | 1 A |
| Power consumption (max) | 6.42 W |
| Power over Ethernet (PoE)Power over Ethernet (PoE) | No |
| Environmental conditionsOperating temperature range | 0 - 40 °C |
| Storage temperature range | -40 - 70 °C |
| Relative humidity range for operation | 10 - 90% |
| Relative humidity range during storage | 5 - 90% |
| Weight and dimensionsWidth | 209 mm |
| Depth | 126 mm |
| Height | 26 mm |
| PackagingCables included | AC |
| User manual | Yes |
Technical data sheet
| No. Ports | 8 |
| Transmission | Gigabit 10/100/1000 |
