Brand: TP-Link

TP-LINK GIGABIT 24-PORT SWITCH TL-SG1024 METAL

TP-LINK GIGABIT 24-PORT SWITCH TL-SG1024 METAL

SKU:TL-SG1024

€99,78 EUR
€99,78 EUR
Sale
In stock · more than 5 units
Shipping calculated at checkout.

The TL-SG1024 is specially designed for Ethernet (10Mbps), Fast Ethernet (100 Mbps) and Gigabit Ethernet (1000Mbps) with Seamless Link. Each port supports a throughput of up to 2000 Mbps in full duplex mode. It is the perfect choice to improve the performance of office and workgroup networks.

Description

The TL-SG1024 is specially designed for Ethernet (10Mbps), Fast Ethernet (100 Mbps) and Gigabit Ethernet (1000Mbps) with Seamless Link. Each port supports a throughput of up to 2000 Mbps in full duplex mode. It is the perfect choice to improve the performance of office and workgroup networks.

24 RJ45 10/100/1000 ports.

All ports support Full/Half Duplex transfer mode for 10/100Mbps and Full Duplex transfer mode for 1000Mbps

Supports Auto-MDI/MDIX function

Supports IEEE802.3X flow control for full-duplex mode and backpressure flow control for half-duplex mode

Store and forward switching

Includes rack mounting kit

Technical specifications

:
Standards and Protocols
IEEE802.3, 802.3u, 802.3ab, 802.3x CSMA/CD, TCP/IPBasic Features
Wire speed performanceAuto-learning and auto-aging MAC addressIEEE802.3X flow control for Full-duplex mode and backpressure for Half-duplex modeBackbone bandwidth
48GbpsMAC address table
8kForwarding rate
10Base-T 14880pps/port 100Base-TX: 148800pps/port 1000BASE-T: 148800pps/portTransmission method
Store-and-ForwardPorts
24 Auto-negotiating 10/100/1000Mbps RJ45 Ports (Auto MDI/MDIX)Network Media
10Base-T UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ù STP (maximum 100m) 100Base-Tx: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ù STP (maximum 100m) 1000Base-T: UTP category 5, 5e cable (maximum 100m)LED Indicators
Power, Link/ActivitySafety & Emissions
FCC, CEDimensions (width x depth x height)
17.3*7.1*1.7 in. (440*180*44 mm)Environment
Operating Temperature 0" ~ 40" (32?~104") Storage Temperature -40" ~ 70" (-40?~158") Operating Humidity 10% ~90%, Non-condensing Storage Humidity: 5% ~90%, Non-condensingPower
100-240VAC, 50/60Hz

Data sheet

Number of Ports 24
Transmission Gigabit 10/100/1000
