Brand: TP-Link
POWERLINE TP-LINK TL-WPA4220 KIT 3 WIFI 300MB
POWERLINE TP-LINK TL-WPA4220 KIT 3 WIFI 300MB
SKU:TL-WPA4220 TKIT
Couldn't load pickup availability
TP-LINK's TL-WPA4220P KIT extends your Internet connection to every room in the house via your home's existing electrical wiring. The TL-WPA4220 features a Wi-Fi Clone button that allows you to extend your wireless coverage, meaning it can automatically copy your router's SSID and password. This way, the TL-WPA4220T KIT simplifies your Wi-Fi setup and allows you to move within your home network.
Description
Features:
Super range extension at the touch of a button – The Wi-Fi Clone button simplifies your Wi-Fi setup and helps you build a unified, seamless home network.
HomePlug AV standard provides high-speed transmissions up to 500Mbps over existing electrical wiring, ideal for lag-free HD or 3D video streaming and online gaming.
Extends 300Mbps wireless connections to previously inaccessible areas of your home and office.
- TL-PA4220T KIT contains two TL-WPA4220 and one TL-PA4010
Technical specifications
| Plug Type EU, UK | |
| Standards and Protocols HomePlug AV, IEEE802.3, IEEE802.3u, IEEE802.11b/g/n | |
| Interface 2 10/100Mbps Ethernet Ports – TL-WPA4220 | |
| 1 10/100Mbps Ethernet Port – TL-PA4010 | |
| Buttons Pairing, Reset, Wi-Fi/Wi-Fi Clone | |
| Power Consumption Maximum | 12.916W (220V/50Hz) |
| Standard Mode | 12.302W (220V/50Hz) |
| Standby Mode | 8.780W (220V/50Hz) |
| LED Indicator PWR, PLC, ETH, Wi-Fi/Wi-Fi Clone | |
| Dimensions (94×54×40mm) 3.7 x 2.1 x 1.6 in. | |
| Range 300 meters over electrical circuit | |
| WIRELESS FEATURES | |
| Frequency 2.4-2.4835GHz | |
| Signal Rate11n | Up to 300Mbps (dynamic) |
| 11g | Up to 54Mbps (dynamic) |
| 11b | Up to 11Mbps (dynamic) |
| Receive Sensitivity270M | -68dBm@10% PER |
| 130M | -68dBm@10% PER |
| 108M | -68dBm@10% PER |
| 54M | -68dBm@10% PER |
| 11M | -85dBm@8% PER |
| 6M | -88dBm@10% PER |
| 1M | -90dBm@8% PER |
| Wireless Security 64/128-bit WEP / WPA / WPA2, WPA-PSK / WPA2-PSK | |
| Advanced Features Enable/Disable Wireless Radio, WMM, Wireless Statistics | |
| Transmission Power CE | <20dBm (2.4GHz) |
| FCC | <30dBm |
| SOFTWARE FEATURES | |
| Modulation Technology OFDM (PLC) | |
| Encryption Powerline Security: | |
| 128-bit AES | |
| Wireless Security: | |
| WEP, WPA/WPA2, WPA-PSK/WPA2-PSK Encryption | |
| Others | |
| Certifications CE, FCC, RoHS | |
| Package Contents 2 TL-WPA4220 and TL-PA4010 Powerline Ethernet Adapters | |
| 2m Ethernet Cable (RJ45) | |
| Utility CD | |
| Quick Installation Guide | |
| System Requirements Windows 2000/XP/2003/Vista, Windows 7/8, Mac, Linux | |
| Environmental Factors Operating Temperature | 0℃~40℃ (32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
